Отзывы о Материнская плата ASRock X299 TAICHI CLX
Рейтинг:
Неплохо
Неплохо
Краткие характеристики:
- форм-фактор: ATX
- сокет LGA2066
- 8 слотов DDR4 DIMM
- 2133-4200 МГц
- 3 слота M.2 PCI-E/SATA 3.0
- 4 слота PCI-E x16
- Wi-Fi 802.11ax
- Bluetooth
- игровая с поддержкой SLI/CrossFireX
- разъемы на задней панели: 1.00
4 отзывов пользователей o ASRock X299 TAICHI CLX
Пользовались
ASRock X299 TAICHI CLX?
Поделитесь своим опытом и помогите другим сделать правильный выбор
НоваГость-7KWHP
14.05.2020
10/10
Оценка пользователя
Великолепно
отличная модель
Очень долго выбирал плату под процессор X серии, рассматривал и TUF MK1/2 и APEX VI, но выбрал таки именно эту.
Здесь есть всё что мне нужно - 8 слотов под память, куча разъемов под вентиляторы, включая специализированные для помпы, возможность разгона, металлический бэкплейт на слоты M2, поддержка ОЗУ 128ГБ+, встроенный Wifi и BT 5.0, т.к. я использую беспроводные девайсы, в том числе и предпочитаю wifi, а не LAN, минимум подсветки, нормальная заглушка задней панели и хороший арсенал USB 3.x портов.
ВАЖНО. У меня плата не запустилась на планках Corsair 16GB. Ни на 1, ни на 2, ни на 4. Это связано с тем что плата имеет самую первую версию биоса 1.20. Пришлось поставить обычную планку Kingston 2666 8gb (В самый первый слот на плате) и обновить биос до 1.50, после чего планки по 16ГБ успешно завелись.
Здесь есть всё что мне нужно - 8 слотов под память, куча разъемов под вентиляторы, включая специализированные для помпы, возможность разгона, металлический бэкплейт на слоты M2, поддержка ОЗУ 128ГБ+, встроенный Wifi и BT 5.0, т.к. я использую беспроводные девайсы, в том числе и предпочитаю wifi, а не LAN, минимум подсветки, нормальная заглушка задней панели и хороший арсенал USB 3.x портов.
ВАЖНО. У меня плата не запустилась на планках Corsair 16GB. Ни на 1, ни на 2, ни на 4. Это связано с тем что плата имеет самую первую версию биоса 1.20. Пришлось поставить обычную планку Kingston 2666 8gb (В самый первый слот на плате) и обновить биос до 1.50, после чего планки по 16ГБ успешно завелись.
skydancer
07.01.2021
8/10
Оценка пользователя
Хорошо
May require BIOS update to use large DIMMs
It took a couple days of internet sleuthing to get this board operational. I was building a 64GB RAM system based on a Core i9-10900X with an RTX 2080 Super GPU. My memory was 4x16GB Corsair DDR4-3200 that are listed on ASRock’s memory QVL. The board would get to POST code 3b PEI_NB_INIT and stop.
The labels on the BIOS EPROMS indicated version P1.20 which was current as of October 2019. The three newer versions up to the current P1.50 all listed better memory support, but I could not update the BIOS without getting to the BIOS.
Fortunately I had another computer with DDR4 8GB DIMMs. I placed one DIMM of 8GB and was able to get it to boot (but only after removing a 2TB Sabrent M.2 SSD. The clue for that was code A2, DXE_IDE_DETECT which I thought odd since the board doesn’t have an IDE interface...but it is more like “storage detect” and the early BIOS didn’t like that NVMe SSD.
Once I got to the BIOS, updating to P1.50 was easy and that allowed me to use the 4x16GB RAM and the SSD.
So beware that you may need a different DIMM just to get to the BIOS if the BIOS version does not support the RAM you plan to use.
I did try contacting ASRock support, but did not receive an answer yet.
The labels on the BIOS EPROMS indicated version P1.20 which was current as of October 2019. The three newer versions up to the current P1.50 all listed better memory support, but I could not update the BIOS without getting to the BIOS.
Fortunately I had another computer with DDR4 8GB DIMMs. I placed one DIMM of 8GB and was able to get it to boot (but only after removing a 2TB Sabrent M.2 SSD. The clue for that was code A2, DXE_IDE_DETECT which I thought odd since the board doesn’t have an IDE interface...but it is more like “storage detect” and the early BIOS didn’t like that NVMe SSD.
Once I got to the BIOS, updating to P1.50 was easy and that allowed me to use the 4x16GB RAM and the SSD.
So beware that you may need a different DIMM just to get to the BIOS if the BIOS version does not support the RAM you plan to use.
I did try contacting ASRock support, but did not receive an answer yet.
Anonymous
07.01.2021
2/10
Оценка пользователя
Ужасно
Stuck on Error Code 36, C0, and d1
The motherboard cannot boot into BIOS. Every time I tried it gets stuck on error codes 36, C0 and d1. C0 and d1 aren't even in the manual. I looked online for solutions, seems like the general advice is reseating the RAM, clearing CMOS, and reseating the CPU.
I've done all of that a bunch of times and I can't get it to work. I also followed the ASRock tech support advice and it doesn't work. No one knows why. Seems like the entire internet is befuddled by this. I would rate this 0 stars, but Amazon doesn't let me.
I've done all of that a bunch of times and I can't get it to work. I also followed the ASRock tech support advice and it doesn't work. No one knows why. Seems like the entire internet is befuddled by this. I would rate this 0 stars, but Amazon doesn't let me.
skydancer
07.01.2021
8/10
Оценка пользователя
Хорошо
It took a couple days of internet sleuthing to get this board operational. I was building a 64GB RAM system based on a Core i9-10900X with an RTX 2080 Super GPU. My memory was 4x16GB Corsair DDR4-3200 that are listed on ASRock’s memory QVL. The board would get to POST code 3b PEI_NB_INIT and stop.
The labels on the BIOS EPROMS indicated version P1.20 which was current as of October 2019. The three newer versions up to the current P1.50 all listed better memory support, but I could not update the BIOS without getting to the BIOS.
Fortunately I had another computer with DDR4 8GB DIMMs. I placed one DIMM of 8GB and was able to get it to boot (but only after removing a 2TB Sabrent M.2 SSD. The clue for that was code A2, DXE_IDE_DETECT which I thought odd since the board doesn’t have an IDE interface...but it is more like “storage detect” and the early BIOS didn’t like that NVMe SSD.
Once I got to the BIOS, updating to P1.50 was easy and that allowed me to use the 4x16GB RAM and the SSD.
So beware that you may need a different DIMM just to get to the BIOS if the BIOS version does not support the RAM you plan to use.
I did try contacting ASRock support, but did not receive an answer yet.
The labels on the BIOS EPROMS indicated version P1.20 which was current as of October 2019. The three newer versions up to the current P1.50 all listed better memory support, but I could not update the BIOS without getting to the BIOS.
Fortunately I had another computer with DDR4 8GB DIMMs. I placed one DIMM of 8GB and was able to get it to boot (but only after removing a 2TB Sabrent M.2 SSD. The clue for that was code A2, DXE_IDE_DETECT which I thought odd since the board doesn’t have an IDE interface...but it is more like “storage detect” and the early BIOS didn’t like that NVMe SSD.
Once I got to the BIOS, updating to P1.50 was easy and that allowed me to use the 4x16GB RAM and the SSD.
So beware that you may need a different DIMM just to get to the BIOS if the BIOS version does not support the RAM you plan to use.
I did try contacting ASRock support, but did not receive an answer yet.
Показаны отзывы 1-4 из 4.
Лучшие цены сегодня на ASRock X299 TAICHI CLX
График изменения цены ASRock X299 TAICHI CLX
Обзоры и руководства на ASRock X299 TAICHI CLX
Характеристи ASRock X299 TAICHI CLX
| Процессор | |
| Производитель процессора : | Intel |
| Сокет : | LGA2066 |
| Поддерживаемые процессоры : | Intel Core X-Series |
| Количество сокетов : | есть |
| Чипсет | |
| Производитель чипсета : | Intel |
| Поддержка SLI/NVLink/CrossFire : | SLI/CrossFireX |
| Чипсет : | Intel X299 |
| Память | |
| Количество слотов оперативной памяти : | 8 |
| Тип памяти : | DDR4 DIMM |
| Режим работы оперативной памяти : | четырехканальный |
| Максимальная частота памяти : | 4200 МГц |
| Максимальный объем памяти : | 256 ГБ |
| Слоты расширения | |
| Количество разъемов M.2 : | 3 |
| Слоты накопителей подробно : | 10 x SATA 6G |
| Аудио/видео | |
| Производитель звукового чипа : | Realtek |
| Звук : | HDA |
| Звуковая схема : | 7.1 |
| Звуковой чип : | Realtek ALC1220 |
| Сеть | |
| Скорость Ethernet : | 2.5 Гбит/с |
| Чипсет Ethernet : | Intel I219-V, Realtek RTL8125AG |
| Беспроводные интерфейсы : | Bluetooth, Wi-Fi 802.11a/b/g, Wi-Fi 802.11ax, Wi-Fi 802.11b, Wi-Fi 802.11n |
| Дополнительные параметры | |
| Поддержка RAID : | SATA RAID 0, 1, 5, 10 |
| Поддержка RAID : | есть |
| Область применения : | игровая |
| Особенности : | восстановление BIOS, поддержка UEFI |
| Форм-фактор материнской платы : | ATX |
| Комплектация : | Антенна Wi-Fi, винт для разъема M.2 x3, диск с ПО, документация, кабель SATA x4, мост 2-Way SLI, отвертка |
| Тип системы охлаждения : | пассивное |
| Задняя панель | |
| Разъемы на задней панели : | 4 x USB 3.2 Gen1 Type-A, SMA (для антенны Wi-Fi), USB 3.2 Gen2x2 Type-C, выход S/PDIF оптический |
| Внутренние разъемы | |
| Внутренние слоты и разъемы : | питания процессора 8-pin + 8-pin, поддержка PCI-E 3.0, разъем питания 24-pin |
